Scag Mowers

Below is a product table listing Scag Mower names and other information. Many mowers can be placed on specialty order by our dealership. Please feel free to contact us for more information as needed.

Liberty Z

ENGINE

• Kawasaki FR air-cooled (18hp, 21hp, 23hp) • Kohler 7000 a/c (26hp)

DRIVE SYSTEM

Dual, Hydro-Gear integrated hydro transaxles with charge pumps & metal gears, internal pump displacement 10cc internal motor displacement 16cc - ZT2800 (36", 48" & 52") - ZT3100 (61")

TRI-PLATE CUTTER DECK

36", 48", 52" & 61" cutter decks

CUTTING HEIGHT

1-1/2" to 4-1/2" in 1/4" increments

GROUND SPEED

0 to 7.0 MPH, 5 MPH reverse

DRIVE WHEELS

• 20x8-10, 4-ply radius edge tires (36") • 20x10-8, 4-ply radius edge tires (48" & 52") • 20x10-10, 4-ply radius edge tires (61")

Freedom Z

ENGINE

Kohler 7000 air-cooled (22hp, 24hp)

DRIVE SYSTEM

Dual Hydro-Gear ZT2800 integrated hydro transaxles with charge pumps & metal gears, internal pump displacement 10cc, internal motor displacement 16cc

CUTTER DECK

48" & 52" cutter decks

CUTTING HEIGHT

1" to 4-1/2" in 1/4" increments

GROUND SPEED

0 to 8.0 MPH, 5 MPH reverse

DRIVE WHEELS

20x10-10, 4-ply radius edge tires

Patriot

ENGINE

• Kawasaki FX air-cooled (22hp, 23hp) • Kohler Command Pro a/c (23hp, 25hp)

DRIVE SYSTEM

• Dual, integrated hydro transaxles with charge pumps & metal gears - SPZ52: Hydro-Gear ZT3100 internal pump displacement 10cc internal motor displacement 16cc - SPZ61: Hydro-Gear ZT3400internal pump displacement 12cc, internal motor displacement 16cc

TRI-PLATE CUTTER DECK

52" & 61" cutter decks

CUTTING HEIGHT

1-1/2" to 5" in 1/4" increments

GROUND SPEED

• SPZ52: 0 to 8.5 MPH, 5 MPH reverse • SPZ61: 0 to 10.0 MPH, 5 MPH reverse

DRIVE WHEELS

• SPZ52: 22x10.5-12, 4-ply radius edge tires • SPZ61: 24x12-12, 4-ply radius edge tires

Tiger Cat II

ENGINE

• Briggs Vanguard air-cooled (32hp) • Kawasaki FX a/c (22hp) • Kawasaki FT EFI a/c (26hp) • Kohler Command EFI a/c (25hp)

DRIVE SYSTEM

• 12cc Heavy-Duty Hydro-Gear Pumps • 14.5ci High-Torque Parker Wheel Motors • Pump-mounted cooling fans

TRI-PLATE CUTTER DECK

• 48", 52", & 61" Velocity Plus decks • 3-year limited warranty. (see page 104 for cutter deck details)

CUTTING HEIGHT

1" to 5" in 1/4" increments

GROUND SPEED

0 up to 12.0 MPH, 5 MPH reverse

DRIVE WHEELS

• 24 x 9.5 - 12, 4-ply radius edge tires (48"/52") • 24 x 12 - 12, 4-ply radius edge tires (61")

Cheetah II

ENGINE

• Briggs Vanguard EFI, air-cooled (37hp) • Kawasaki FX a/c (31hp)

DRIVE SYSTEM

Hydro-Gear ZT-5400 transaxle, 2-speed: internal pump displacement 16cc, internal motor displacement 21cc

TRI-PLATE CUTTER DECK

61" & 72" Velocity Plus deck • 3-year limited warranty (see page 104 for cutter deck details)

CUTTING HEIGHT

1-1/4" to 5" in 1/4" increments

GROUND SPEED

• 0 to 16 MPH in high range; 8 MPH reverse • 0 to 12 MPH in low range; 5 MPH reverse

DRIVE WHEELS

24 x 12 - 12, 4-ply radius edge tires

Turf Tiger II

ENGINE

• Briggs Vanguard air-cooled (31hp, 35hp) • Briggs Vanguard EFI, a/c (37hp) • Kawasaki DFI, liquid-cooled (31hp) • Kohler Command LP EFI, a/c (25hp) • Kubota, Diesel, l/c (25hp)

DRIVE SYSTEM

• 16cc Heavy-Duty Hydro-Gear Pumps • 18ci High-Torque Parker Wheel Motors • Auxiliary hydraulic oil cooler, large hydro tank, and pump-mounted cooling fans

TRI-PLATE CUTTER DECK

• 52", 61", & 72" Velocity Plus deck • 3-year limited warranty (see page 104 for cutter deck details)

CUTTING HEIGHT

1.5" to 6" in 1/4" increments

GROUND SPEED

• 0 to 12.0 MPH, 6.0 MPH reverse (gas/LP) • 0 to 10.0 MPH, 6.0 MPH reverse (diesel)

DRIVE WHEELS

• 26 x 9.5 - 12, 6-ply radius edge tires (52") • 26 x 12 - 12, 6-ply radius edge tires (61" & 72")

SVR V-Ride II

ENGINE

• Kawasaki FX A/C (16hp, 19hp, 22hp, 23hp, 25hp) • Kohler Command EFI, A/C (25hp, 29hp) • Briggs Vanguard EFI, A/C (37hp)

DRIVE SYSTEM

• 48", 52" & 61": Heavy-Duty Hydro-Gear 12cc pumps and 14ci high-torque Parker wheel motors • 32" & 36": 10cc pumps & 12ci motors

TRI-PLATE CUTTER DECK

• 32" & 36" Advantage cutter deck • 48", 52" & 61" Velocity Plus cutter decks (see page 102 for cutter deck details)

CUTTING HEIGHT

1-1/2" to 4-1/2" in 1/4" increments

GROUND SPEED

• 0 to 8.5 MPH forward (32" & 36"), 5 MPH reverse • 0 to 10.5 MPH forward (48", 52" & 61"), 5 MPH reverse

DRIVE WHEELS

• 20.0 x 6.5 - 10 tubeless, 4-ply (32") • 20.0 x 10.0 - 8 tubeless, 4-ply (36") • 24.0 x 9.5 - 12 tubeless, 4-ply (48" & 52") • 24.0 x 12.0 - 12 tubeless, 4-ply (61")

SW Belt Drive

ENGINE

Kawasaki FS recoil (14hp, 15hp)

DRIVE SYSTEM

Twin power belts with 5-speed Peerless transmission

CUTTER DECK

• 32" standard cutter deck • 36" Advantage cutter deck • 48" & 52" Velocity Plus cutter deck (see page 102 for cutter deck details)

CUTTING HEIGHT

1-3/4" to 4-1/2" in 1/4" increments

GROUND SPEED

2 to 6 MPH forward, 2 MPH reverse

DRIVE WHEELS

• 13.0 x 6.50 - 6 (36", 48" & 52") • 13.0 x 5.00 - 6 (32")

SWZ Hydro Drive

ENGINE

• Kawasaki FS recoil (14hp, 15hp, 18hp) • Kawasaki FS electric start (22hp)

DRIVE SYSTEM

Hydraulic drive featuring two heavy-duty 10cc pumps and two cast-iron high torque motors.

CUTTER DECK

• 36" Advantage deck • 48", 52", & 61 Velocity Plus cutter decks (see page 102 for cutter deck details)

CUTTING HEIGHT

1-3/4" to 4-1/2" in 1/4" increments

GROUND SPEED

0 to 7.4 MPH forward, 3 MPH reverse

DRIVE WHEELS

16.0 x 6.50 - 8

SWZT Hydro Drive

ENGINE

• Kawasaki FS recoil (14hp, 15hp, 18hp) • Kawasaki FS electric-start (18hp, 22hp)

DRIVE SYSTEM

Dual Hydro-Gear ZT-2800 transaxles, internal pump displacement 10cc, internal motor displacement 16cc

CUTTER DECK

36", 48", 52" & 61" cutter decks

CUTTING HEIGHT

1-1/2" to 4-1/2" in 1/4" increments

GROUND SPEED

Up to 7 MPH forward, 3 MPH reverse

DRIVE WHEELS

• 18.0 x 6.5 - 8 (36" models) • 18.0 x 8.5 - 8 (48", 52" & 61" models)
